TIP36SC125N2U6L0N
Castor TIP36SC125N2U6L0N

36,60  incl. 22% VAT
30,00  excl. 22% VAT

Available on backorder

Castor TIP36SC125N2U6L0N

Filters Sort results
Reset Apply
back brake,
stainless steel,
ø125mm,
polyamide (PA) wheel center,
polyurethane (PU) tread,
plain bearing,
dyn. load capacity
200kg

36,60  incl. 22% VAT
30,00  excl. 22% VAT

Available on backorder

Add 50,00  more to get free shipping!
Extra Features
  • Stock orders 2-3 days delivery
  • Back orders 7-14 days delivery
  • Free Shipping from 50EUR

Description

Stainless steel fork with a ball bearing, fastening by plate with hole spacing 80/77x60mm, fork with material thickness 2.50mm (fastening) and 2.00mm (fork), inner part of wheel made of polyamide, tread made of thermoplastic polyurethane 95° Shore A, width of the wheel center 50mm, plain bearing without separate bearing guard.

Additional information

Product SKU

TIP36SC125N2U6L0N

Standard Compliance

DIN EN 12532

Series

N2U6

Fastening

Brake and Direction

back brake

Material of the Wheel

polyamide (PA) wheel center

Tread

Temperature range

-40°C to +80°C

Wheel Diameter

125mm

Load Capacity

200kg

Total Hight

155mm

Width of Tread

32mm

wheel hub Width

50mm

Offset

40mm

Dimension of Plate

96x80mm

Hole Spacing of the Plate

80/77x60mm

Swivel Radius

120mm

Wheel Bolt Size

M8

Bushing Diameter

12mm

Wheel Bearing

plain bearing

Wheel Color

Gray and Red

Special Features

stainless steel
