Castor TBP25WC100N2U6R1W

12,20  incl. 22% VAT
10,00  excl. 22% VAT

Available on backorder

Castor TBP25WC100N2U6R1W

Filters Sort results
Reset Apply
back brake,
ø100mm,
polyamide (PA) wheel center,
polyurethane (PU) tread,
roller bearing,
dyn. load capacity
150kg

12,20  incl. 22% VAT
10,00  excl. 22% VAT

Available on backorder

Add 50,00  more to get free shipping!
Extra Features
  • Stock orders 2-3 days delivery
  • Back orders 7-14 days delivery
  • Free Shipping from 50EUR

Description

Galvanized sheet steel fork with a ball bearing, fastening by plate with hole spacing 80/77x60mm, fork with material thickness 2.50mm (fastening) and 2.50mm (fork), inner part of wheel made of polyamide, tread made of thermoplastic polyurethane 95° Shore A, width of the wheel center 40mm, roller bearing, metal bearing guard.

Additional information

Product SKU

TBP25WC100N2U6R1W

Standard Compliance

DIN EN 12532

Series

N2U6

Fastening

Brake and Direction

back brake

Material of the Wheel

polyamide (PA) wheel center

Tread

Temperature range

-40°C to +80°C

Wheel Diameter

100mm

Load Capacity

150kg

Total Hight

125mm

Width of Tread

32mm

wheel hub Width

40mm

Offset

40mm

Dimension of Plate

105x80mm

Hole Spacing of the Plate

80/77x60mm

Swivel Radius

127mm

Wheel Bolt Size

M8

Bushing Diameter

12mm

Weight

0.83kg

Wheel Bearing

roller bearing

Wheel Color

Gray and Red

Rubber Shore

95° Shore A
