Castor BSH12C0100P2T2P0N
Filters Sort results
Reset Apply
back brake, ø100mm, polypropylene (PP) wheel center, thermoplastic rubber tread, plain bearing,  |
Add 50,00 € more to get free shipping!
Extra Features
- Stock orders 2-3 days delivery
- Back orders 7-14 days delivery
- Free Shipping from 50EUR
Description
Galvanized sheet steel fork with a ball bearing, fastening by bolt, hole ø11mm, fork with material thickness 2.00mm (fastening) and 2.00mm (fork), inner part of wheel made of polypropylene, tread made of thermoplastic rubber 95° Shore A, width of the wheel center 36mm, plain bearing.
Additional information
| Product SKU | BSH12C0100P2T2P0N |
|---|---|
| Standard Compliance | DIN EN 12530 |
| Series | P2T2 |
| Fastening | |
| Brake and Direction | back brake |
| Material of the Wheel | polypropylene (PP) wheel center |
| Tread | |
| Temperature range | -20°C to +60°C |
| Wheel Diameter | 100mm |
| Load Capacity | 60kg |
| Total Hight | 122mm |
| Width of Tread | 23mm |
| wheel hub Width | 36mm |
| Offset | 24mm |
| Fastening Bolt Hole Diameter | 11mm |
| Swivel Radius | 80mm |
| Wheel Bolt Size | M6 |
| Bushing Diameter | 8mm |
| Weight | 0.29kg |
| Wheel Bearing | plain bearing |
| Wheel Color | Grey |
| Rubber Shore | 95° Shore A |
